Technical features
Charging capacity: Up to 3.5KW
Input/Output power: 230VAC±20%,50/60Hz,8A-10A-13A-16A adjustable,1-phase
RCD: TypeAC30mA/RCMU(TypeA+DC6mA)(Optional)
Standby power:<2W
Measuring accuracy: 1%
User interface: LED,OLED,Select button
Certificate/Compliance: CE/IEC61851-1,IEC61851-22,SAEJ1772
Charging Interface: 5Mcable,Type2 Plug
Power Cord Pug: Schuko/NEMA6-20P
Physical properties
Protection: IP65,IK10
Special Protection: Temperature sensor and plug a dapter
Cooling: Natural cooling
Operating temperature: -30℃ to +55℃
Humidity: Max.95%(non-regulating)
Product Dimensions: 210'88*50(L'W'H)mm
Package Dimension: 350~320~60(L“W^H)mm
Net Weight: 2.02Kg
Gross Weight: 2.25Kg
